| Logic Family |
LS |
| Logic Function |
D Type |
| Input Type |
Single Ended |
| Output Signal Type |
Differential |
| Triggering Type |
Positive Edge |
| Polarity |
Inverting, Non-Inverting |
| Mounting Type |
Through Hole |
| Package Type |
PDIP |
| Pin Count |
14 |
| Set/Reset |
Yes |
| Number of Elements per Chip |
2 |
| Maximum Propagation Delay Time @ Maximum CL |
40 ns @ 5 V |
| Dimensions |
19.3 x 6.35 x 4.57mm |
| Propagation Delay Test Condition |
15pF |
| Maximum Operating Supply Voltage |
5.25 V |
| Height |
4.57mm |
| Minimum Operating Supply Voltage |
4.75 V |
| Length |
19.3mm |
| Maximum Operating Temperature |
+70 °C |
| Minimum Operating Temperature |
0 °C |
| Width |
6.35mm |
